Welded Cylinders
Double-acting welded hydraulic cylinders—compact, robust structure suited for mobile and heavy-duty industrial applications with higher strength and reduced weight.
Compact Robust Design
Double acting welded cylinders provide powered force in both extend and retract directions using hydraulic pressure. The barrel and end caps are welded directly, forming a compact, robust structure suited for mobile and heavy-duty industrial applications. Welded design offers higher strength, reduced weight, and eliminates the need for tie-rods in space-constrained installations.
How They Work
Bi-Directional Force
Hydraulic pressure is applied alternately to each side of the piston for extension and retraction.
Welded Construction
The welded construction joins end caps to the barrel for strength and compactness.
Speed Control
Flow controls manage cylinder speed; optional cushions absorb end-of-stroke impact.
Dual Ports
Dual ports provide powered actuation in both directions.
Sealing System
Seals and wipers ensure hydraulic integrity and contamination control.
When to Use
Ideal applications for welded cylinders
Applications requiring compact cylinders with high durability
Mobile and construction equipment where space is limited
Systems needing robust, leak-free performance in harsh environments
Long-term installations where low maintenance and reliability are priorities
Industrial or agricultural equipment requiring both extend and retract power
Custom Engineering
We design and manufacture welded cylinders tailored to your specific requirements and applications.
- Custom MountsRod ends and stroke lengths for OEM integration
- Corrosion-ResistantCoatings and stainless builds for harsh environments
- Harsh Environment SealsSpecial seal systems for abrasive conditions
- Position FeedbackIntegrated sensors for automation
- Multi-Cylinder SyncSynchronization for multi-cylinder operation
Key Benefits
- Compact welded body: For confined spaces
- Strong, leak-free joints: For rugged service
- Fewer external parts: Than tie-rod cylinders
- Excellent alignment: And rigidity under load
- Ideal for: Mobile, agricultural, and OEM applications
Operating Envelope
- Pressure: Up to 450 bar (6,526 psi)
- Speed: Up to 0.5 m/s
- Temperature: −20°C to +80°C (extended range on request)
- Media: Mineral oil (HLP); water-glycol and fire-resistant fluids on request
Industry Applications
Welded cylinders power critical operations in demanding environments
Agricultural
Implements and construction attachments
Material Handling
Lifting and tilting systems
Refuse & Compactors
Trucks and mobile hydraulics
Forestry & Mining
Heavy-duty equipment
Industrial Presses
Forming machines
Hydraulic Steering
Stabilizing systems
Marine & Offshore
Actuators
Custom OEM
Applications
